HN-570 Technical parameters:
|
Model |
HN-570 |
|
Working votage |
DC 6~17V |
|
Working current |
600mA_12V/7.2W（30dBm output power） |
|
Transmission interface |
|
|
Bandwidth |
2.0/4.0M |
|
Operating frequency |
830MH~930MHZ Stepping 1MHz (can be customized other frequencies) |
|
Output power |
10dBm-30dBm |
|
transmission speed |
4Mbps |
|
Receiving sensitivity |
-90dBm |
|
Encryption |
128 bit AES encryption |
|
Modulation |
COFDM |
|
Modulation Type: |
QPSK,QAM16,QAM64 |
|
RF interface |
SMA female |
|
Parameter control |
By adjusting the parameters of OLED control panel |
|
Dimension |
82mm*55mm*16mm |
|
Weight |
125g |
