Vehicle-mounted video receiver
  • Description
  • Feature
  • Specification
  • Accessories
  • HN-120R Vehicle-mounted HD H.264/MPEG2 COFDM wireless video transmission receiver,Using standard 1U frame to design,

    with simple and efficient control interface, which can output a multi-channel video including high definition and standard definition video at the same time.

    Widely used in security, fire fighting, radio and television, emergency communications and other applications.

    Receiving the wireless signal in the high speed movement or NLOS(non line of sight) condition to realize the remote video transmission and monitoring.

  • Support H.264  HD1080P/SD resolution

    Support non line of sight (NLOS) transmission in high-speed movement
    Digital operation panel and display, easy to use
    Standard 1U case,small volume,good extension

    Aluminum alloy design, dustproof,moistureproof,anti vibration,anti impact

  • HN-120R HD receiver technical parameters





     Power consumption


     Receiving Sensitivity


     Video output

     BNC port,SD Analog video output

     HDMI:HD digital video output



     Radio Frequency

    300MHz~860MHZ,Stepping 1MHz (other frequencies on request)





     Parameter adjustment

     Through the control panel to set the relevant parameters

     Audio output connection

     BNC,Analog stereo output

     RF signal input port

     N(50Ω)High performance dual channel diversity reception

     Working temperature


     Operating humidity



     480mm*220mm*44mm(Standard 1U case)
